Ferns of the Eloise Butler Wildflower Garden

The oldest public wildflower garden in the United States

thumbnail

Common Name
Marginal Wood Fern (Marginal Shield Fern, Evergreen Wood Fern)



Scientific Name
Dryopteris marginalis (L.) A.Gray



Plant Family
Wood Fern Family (Dryopteridaceae)

Garden Location
Historical - not extant



Prime Season
Spring to Autumn



Fern terms



Shape: Marginal Fern is an erect fern, growing in scattered clumps in woodland settings. The upright arching green fronds grow from 10 to 40 inches in height with various old withered fronds at their base.

Fronds: Fronds are bluish-green above, light green under, retaining their color through the winter. The blades are ovate to lanceolate, up to 10 inches wide, widest about half of the way up from the base with the tip usually arching. There are no aromatic glands. Fronds are leathery, and die back after new fronds emerge in Spring. Sterile fronds look the same. The central rachis is green with pale tan small scales on the underside. The grooved stipe is 1/4 to 1/3 the length of the frond. The tawny scales on the stipe are dense and in tufts.

Pinnae: The pinnae are lance shaped and on larger fronds rapidly taper to tips which typically turn upward. Pinnae are mostly in the plane of the blade, not tilted, and may have a very short stalk. The division pattern is pinnate-pinnatifid to bi-pinnate near the base. On the rachis, the pinnae are sub-opposite each other (slightly offset). The upper side of the costa is grooved but the groove does not meet the groove on the rachis. There may be 15 to 20 pairs of pinnae on the rachis.

Pinnules: There will be 20+/- pairs of short pinnules. Margins of the pinnules are entire or slightly lobed without teeth. Pinnule tips are blunt. There is a distinguishing difference in length of the adjacent basal pinnules. First, the basal (inner-most) pinnules are typically longer than those above it on the same side of the pinna costa. Second, the lower basal pinnule (the basiscopic pinnule) is longer than the opposing upper pinnule (the acroscopic pinnule).

Fertility: The sori are placed on the back of the pinnule near the pinnule margin, either single or in a single well spaced row on either side of the pinnule. Sori are rounded with a kidney shaped indusia covering them, without glands.



Habitat: Marginal Fern grows from a stout ascending rhizome that is covered with bright shiny scales. It is found in rocky wooded slopes, woodland edges and ravines in partial shade and based on the Minnesota population, also in sunny stony bluffs and ridges. Soils can be acidic, neutral or alkaline. It forms a nice clump but is not an agressive spreader. D. marginalis hybridizes with other species but hybrids have malformed spores and position of sori not quite marginal.

Names: Marginal Fern gets its common name from the position of the sori on the underside margin of the pinnules. The genus name Dryopteris, is derived from two Greek words, drys, meaning 'tree', and pteris, meaning 'fern'. Many members of this genus are commonly referred to as "wood" ferns and hence the name. The species, marginalis, meaning 'margined', refers to the sori placement. The author names for the plant classification are: The first to publish information was '(L.)' which refers to Carl Linnaeus (1707-1778), Swedish botanist and the developer of the binomial nomenclature of modern taxonomy. His work was amended by ‘A.Gray’ who is Asa Gray (1810-1888), American botanist, Professor of Natural History at Harvard and instrumental in unifying plant knowledge of North America and author of Gray’s Manual - Manual of the Botany of the Northern United States, from New England to Wisconsin and South to Ohio and Pennsylvania Inclusive.

In earlier years the plant was first classified as Polypodium marginale by Linnaeus, then Aspidium marginale in 1806 and finally reaching D. marginalis in 1848, although in Eloise Butler's time the prior classification was still much used.

Comparisons: There are many species of wood ferns with 14 in North America alone. Other members of the Wood Fern Family are Spinulose Woodfern, Dryopteris carthusiana; the Crested Wood Fern, Dryopteris cristata; Male Fern, Dryopteris filix-mas; and Goldie's Fern, Dryopteris goldiana. The key to Marginal Fern is 1) no aromatic glands, 2) blades pinnate-pinnatifid to bi-pinnate with the pinnules having margins entire or slightly lobed, no teeth, and a blunt tip, 3) different lengths of the basal pinnules, 4) dense brown scales of a single type on the stipe, 5) pinnae lance-like, long and rapidly tapering to the tip, 6) large sori at the margin of the pinnae, 7) fronds leathery and evergreen with older withered fronds at the base.

See bottom of page for notes on the Garden's planting history, distribution in Minnesota and North America, lore and other references.

frond Drawing

Above: A frond - widest about the middle, leathery, opposite pinna slightly offset. Drawing from Britton, N.L., and A. Brown. 1913. An illustrated flora of the northern United States, Canada and the British Possessions. 3 vols. Charles Scribner's Sons, New York.

Below: 1st photo - The upper side of a pair of smaller pinnae - note the bluish-green color and the groove on the upper side of the pinna costa and the central rachis. 2nd photo - The under side of the pinna. Note - the basal pinnules are larger than the others and the lower basal pinnule is longer than the basal upper pinnule.

pinnae upper side Pinnae under side

Below:The sori are along the margins of the pinnules. 1st photo - immature sori, 2nd photo - maturing sori. Note the kidney shaped white indusia.

immature sori mature sori

Below: 1st photo - the tawny scales of the stipe. 2nd photo - Fiddlehead.

Stipe Fiddlehead
full plant
Marginal Fern Clump

Notes:

Notes: Marginal Fern is not indigenous to the Garden. Eloise brought in the first plants in September 1908 from Bear Mountain, Mass. In 1909 she brought in more from the same source. Six from Gillett's Nursery in Southwick Mass in 1918. In Miss Butler's day the plant was still frequently classified as Aspedium marginale, although D. marginalis had already been assigned. Martha Crone added additional plants in 1934 obtained from Ferndale Nursery in Askov Minn, operated by a Mr. Burgess. More were planted in 1955 and in 1956 she added 55 plants from The Three Laurels, in Marshall NC, when she was developing the Fern Glen. The fern has since died out in the Garden. It was listed on the 1986 census and on plant lists as late as 2002.

Marginal Fern is quite rare in Minnesota. It was not discovered in the State until 1981 when some were found in Houston County. Since then a smaller group was found in neighboring Filmore County. The fern was elevated from "Threatened" to the "Endangered Species List" in 2013. The range of Marginal Fern in North America is generally east of Minnesota from the Mississippi River to the east coast, excepting Florida and Louisiana. In Canada it is reported in all provinces from Ontario eastward and has also been found in Greenland.



References and site links

References: Plant characteristics are generally from sources 1A, 32, W2, W3, W7 & W8 plus others as specifically applied. Distribution principally from W1, W2 and 28C. Planting history generally from 1, 4 & 4a. Other sources by specific reference. See Reference List for details.
